| Handheld Printing Solution | |||
| Printer Model | Mobile S | Mobile ONE | |
| Display | 3.5″ color LCD with LED backlight | ||
| LED Indicators | Alarm, Ink low, Print, Run, Remote on/off | ||
| Input Device | Pocket-sized IR remote keypad | ||
| Print Engine Technology | Thermal Inkjet | ||
| Available Languages | English, Chinese (Traditional), Chinese (Simplified), Japanese, Russian, Korean, German, Portuguese, Spanish, French, Italian, Turkish, Hungarian, Slovak, Czech, Swedish, Romanian, Serbian Latin, Serbian Cyrillic, Bulgarian, Polish, Vietnam | ||
| Max. Printing Resolution | 400(h) x 600(v) dpi Print quality is dependent on resolution and speed |
400(h) x 300(v) dpi Print quality is dependent on resolution and speed |
|
| Max. Printing Speed | 60.96 Meters/Mins at 300 dpi setting | ||
| Max. Printing Distance | Recommended 6mm from nozzle to surface | ||
| Message Height | Up to 12.7mm (0.5″) Selectable font size: 1.0mm, 1.4mm, 1.8mm, 2.7mm, 3.6mm, 4.5mm, 5.0mm, 5.5mm, 6.4mm, 8mm, 10mm, 11mm, 12.7mm |
Up to 25.4mm (1 inch) Selectable font size: 2.0mm, 2.8mm, 3.6mm, 5.4mm, 7.2mm, 9mm, 10mm, 11mm, 12.8mm, 16mm, 20mm, 22mm, 25.4mm |
|
| Print Capabilities | Text, String, Logo, Shift, Counter, DateTime, Expiration Date, Barcode | ||
| Barcodes | Code-128, ITF-14(SCC-14), NVE(SSCC-18), EAN-13, EAN-14, EAN-8, EAN-128, PDF417, Data Matrix, QR Code, DUN-14, GS1 Datamatrix, GS1 DataBar, GS1 DataBar EXP, GS1 QR CODE, UPCA, UPCE, Codabar, Aztec Code, INTER25, CODEBAR, Code-39 | ||
| Input/Output | RS-485, RS-232, USB, Wi-Fi | ||
| Message Storage Capacity | Store up to 999 messages | ||
| Operating Temperature | 5⁰C – 40⁰C (41⁰F – 104⁰F) | ||
| Encoder | Embedded (400DPI) | ||
| Dimensions | 219 mm (L) x136.9 mm (W) x 143.5 mm (H) | ||
| Weight | 1.13kgs (2.5 lbs) Cartridge and battery not included | ||
| Standard Accessories | Battery, battery charger with adapter, USB disk, remote control | ||
| Optional Accessories | Wi-Fi dongle, RS-485 to USB converter, Clock stabilizer | ||
| PC Software | Message Pro II, Net Commander | ||
| Printer Control Protocol | ANSER U2 Net Protocol | ||
| Battery | Rated Capacity | 1,840 mAh | |
| Standard Voltage | 11.1V | ||
| Charging Voltage ( Max ) | 12.6V | ||
| Charging Hours ( Max ) | 2 hours | ||
| Operating Temperature | Charge | 0°C – 45°C (32°F – 113°F) | |
| Discharge | -20°C – 60°C (-4°F- 140°F) | ||
| Dimensions | 100.3 (L) x 56.3 (W) x 21 (H) mm | ||
| Weight | 150g (0.33 lbs) | ||
| Cycle Life | More than 300 cycles | ||
| Continuous Printing Hours | 4 hours | ||
| Power Adapter of Battery Charger | 12.6V 2A | ||
| Stand-by Time | 6 hours for MobileONE 4.5 hours for MobileS |
||
